Estimating the Payback Period of Additional Insulation

Written by  The U.S. Department of Energy's Office of EERE

Use the equation below to estimate the cost effectiveness of adding insulation in terms of the "years to payback" for savings in heating costs. Years to payback is the time required for the insulation to save enough fuel from heating (at present prices) to pay for itself. A simple payback is the initial investment divided by annual savings after taxes.





Estimating the Payback Period of Additional Insulation





Topic Summary

The equation works only for uniform sections of the home. For example, you can estimate years to payback for a wall or several walls that have the same R-values, if you add the same amount of insulation everywhere. Ceilings, walls, or sections of walls with different R-values must be figured separately. Subtract the areas of windows and doors when estimating payback for wall insulation.

The cost of the energy source is also a key factor in determining payback. Energy prices vary widely from region to region and season to season. Other factors, such as the rate of production and inventories of fuels nationwide, can also affect local energy prices. The weather from year to year also varies, so your energy costs from year to year will vary as well. To figure the cost of energy, consult your local utility for a rate schedule, or save your energy bills and plug your specific costs into this formula:

Years to Payback = (C(i) × R(1) × R(2) × E) ÷ (C(e) × [R(2) - R(1)] × HDD × 24)

To calculate the payback, you must supply the following information:

C(i) = Cost of insulation in $/square feet. Collect insulation cost information; include labor, equipment, and vapor barrier if needed.

C(e) = Cost of energy, expressed in $/Btu.

  • To calculate the cost of energy, divide the actual price you pay per gallon of oil, kilowatt-hour (kWh) of electricity, gallon of propane, or therm (or per one hundred cubic feet [ccf]) of natural gas by the Btu content per unit of fuel.
  • To figure the price you pay per unit, take the total amount of your bills (for oil, electricity, propane, or natural gas) during the heating season, and divide it by the total number of gallons, kWh, or therms you consumed during those months. Use the following values for fuel Btu content:
    • #2 Fuel Oil = 140,000 Btu/gallon
    • Electricity = 3,413 Btu/kWh
    • Propane = 91,600 Btu/gallon
    • Natural Gas = 103,000 Btu/ccf or 100,000 Btu/therm

E = Efficiency of the heating system. For gas, propane, and fuel oil systems this is the Annual Fuel Utilization Efficiency or AFUE. Typical AFUE values are 0.6 to 0.88 for oil or propane furnaces, and 0.7 to 0.95 for natural gas furnaces. Older systems are usually less efficient. Use E = 1.00 for baseboard electric systems. For heat pumps, use the Coefficient of Performance or COP for E; where E = 2.1 to 2.5 for conventional heat pumps, and E = 3.2 to 3.5 for geothermal heat pumps.

R(1) = Initial R-value of section

R(2) = Final R-value of section

R(2) - R(1) = R-value of additional insulation being considered

HDD = Heating degree days/year. This information can usually be obtained from your local weather station, utility, or oil dealer.

24 = Multiplier used to convert heating degree days to heating hours (24 hours/day).

Example

Suppose that you want to know how many years it will take to recover the cost of installing additional insulation in your attic. You are planning to increase the level of insulation from R-19 (6-inch fiberglass batts with moisture barrier on the warm side) to R-30 by adding R-11 (3.5-inch unfaced fiberglass batts). You have a gas furnace with an AFUE of 0.88. You also pay $0.87/therm for natural gas. Let's also suppose that you supply the following values for the variables in the formula.

C(i) = $0.18/square foot

C(e) = ($0.87/therm)÷(100,000 Btu/therm) = $0.0000087/Btu

E = 0.88

R(1) = 19

R(2) = 30

R(2) - R(1) = 11

HDD = 7000

By plugging the numbers into the formula, you obtain the years to payback:

Years to Payback = (C(i) × R(1) × R(2) × E) ÷ (C(e) × [R(2) - R(1)] × HDD × 24)

Years to Payback = (0.18 × 19 × 30 × 0.88) ÷ ($0.0000087 × 11 × 7000 × 24) 90.288 ÷ 16.077 = 5.62 years


Article source: The U.S. Department of Energy’s Office of Energy Efficiency and Renewable Energy (EERE). For the most up-to-date information please visit the EERE website.
